3 POLE 32A ISOLATOR LARGE
Tesla Electrical Components | SKU: TESTWIS3P32L
• Weather protected Isolating Switches are suitable for any external application
• Range for single and triple pole switches are 20 Amps, 32 Amps and 63 Amps
• Easily terminated and more wiring room with the base mount mechanism
• Fixed Earth and Neutral connector bars with dual clamping screws per tunnel
• Insulated caps that cover base mounting screws to protect from any live cables
• Dual 25mm screwed conduit entries top and bottom which allows four ways to surface wire the switch.
• Each unit is supplied with screwed conduit plugs and screwed reducers for easy connection to 25mm or 20mm conduits and screw caps. Screw caps must be installed to ensure IP Rating.
• For security, a hole is provided for padlocking the lever in the OFF position
• Has impact resistant base and cover which will survive the hardest knocks in almost any installation.
• Utilisation category: AC22A, AC23A
|Brand||Tesla Electrical Components|
|Unit Of Measure||ea|
